LWMLD6 : 6" Lumen Cannon Wall Mount 1100lm - 6000lm (18W-60W)

6" Lumen Cannon Wall Mount 1100lm - 6000lm (18W-60W)
6" Lumen Cannon Wall Mount 1100lm - 6000lm (18W-60W) 6" Lumen Cannon Wall Mount 1100lm - 6000lm (18W-60W) 6" Lumen Cannon Wall Mount 1100lm - 6000lm (18W-60W) 6" Lumen Cannon Wall Mount 1100lm - 6000lm (18W-60W) 6" Lumen Cannon Wall Mount 1100lm - 6000lm (18W-60W)
Compatible Items Similar Items

Downloads

Add to Project Folder Add to Project Folder
?

Description

Architectural-grade surface mount LED downlight housing for medium to high ceilings combines energy efficiency with powerful lumen output. Perfect for atriums, churches, lobbies, and airports that have high ceilings.

Benefits

  • 120V/277V Input Standard, 347V Available
  • Exclusive UniDim™ Universal LED Dimming Option Works with 0-10V, ELV and Incandescent Controls
  • 1% Dimming available with 120VAC, 0-10V, DALI, DMX AND Lutron Ecosystem
  • Wide spectrum of Color Temperatures
  • Sturdy Steel Fixture Housing, <8lbs
  • Pre-Installed Wall-Mount Bracket
  • Suitable for dry locations
  • Multiple Wireless Control Options

Available Features
?

  • Emergency
  • ETL Listed
  • US Assembled
  • Dedicated LED
  • Ambient Lighting
  • Downlight
  • Uplight
  • Daylight Sensor
  • Occupancy Sensor
  • 120V
  • 277V
Inquire about this Product! Click Here

Order Configurator

$0.00
Add to Project Folder Add to Project Folder
?

1 Lumens are nominal delivered lumens. See Photometry page for exact values.
2 Special Order. Minimum order quantity (MOQ), extended lead time may apply. Consult Factory.
3 (UE-DEC) & (UE-DHL) not available for (550) lumen package.
4 (1) Blank: 3000K, 80CRI not available with (350) or (450) lumen package. (2) -T27: 2700K, 80CRI not available with (101), (151),(210) or (320). (3) -T27-C97: 2700K, 97CRI not available with (550). (4) -T35: 3500K, 80CRI not available with (350), (450), or (550). (5) -T40: 4000K, 80CRI not available with (550).

347 Input with 0-10V available. Consult Factory for details and lead time.
Energy Efficient Chip-On-Board (COB) Singular LED Light source provides for smooth uniform light output, eliminating the multiple shadow effect seen by multiple LED source products.
Binned with 3-Step MacAdam Ellipses as recommended by Ansi Standard. Available in 2700k, 3000k, 3500k, 4000k, 5000k.
Custom RAL Color: Please note that we appreciate custom finishes. Custom finishes are subject to a special paint setup fee for the quantity ordered. Extended lead times may apply.Consult Factory.

Description

Perfect for atriums, churches, lobbies, and airports that have high ceilings.

Dimming Diagrams
