LWMLD4 : 4" Lumen Cannon Wall Mount Architectural Downlight 1000LM - 2600LM (10W-30W)

4" Lumen Cannon Wall Mount Architectural Downlight 1000LM - 2600LM (10W-30W)
4" Lumen Cannon Wall Mount Architectural Downlight 1000LM - 2600LM (10W-30W) 4" Lumen Cannon Wall Mount Architectural Downlight 1000LM - 2600LM (10W-30W) 4" Lumen Cannon Wall Mount Architectural Downlight 1000LM - 2600LM (10W-30W) 4" Lumen Cannon Wall Mount Architectural Downlight 1000LM - 2600LM (10W-30W) 4" Lumen Cannon Wall Mount Architectural Downlight 1000LM - 2600LM (10W-30W) 4" Lumen Cannon Wall Mount Architectural Downlight 1000LM - 2600LM (10W-30W) 4" Lumen Cannon Wall Mount Architectural Downlight 1000LM - 2600LM (10W-30W)
Compatible Items Similar Items

Downloads

Add to Project Folder Add to Project Folder
?

Description

Architectural-grade wall mount LED downlight housing for medium to high ceilings combines energy efficiency with powerful lumen output. Perfect for atriums, churches, lobbies, and airports that have high ceilings

Benefits

  • 120V/277V Input Standard, 347V Available
  • Exclusive UniDim™ Universal LED Dimming Option Works with 0-10V,
    ELV and Incandescent Controls
  • 120V or 120V/277V Input Options
  • Available TRIAC dimming available
  • Wide spectrum of Color Temperatures
  • Mounts to typical standard J-Box, perfect for ceilings up to 12’
  • Small aperture and slender profile for discrete illumination
  • Pendant mounting available for flat and sloped ceilings
  • Suitable for dry locations
  • Pre-installed Wall-Mount Brackets
  • Multiple Wireless Control Options

Available Features
?

  • Emergency
  • ETL Listed
  • US Assembled
  • Ambient Lighting
  • Downlight
  • Daylight Sensor
  • Occupancy Sensor
  • 120V
  • 277V
Inquire about this Product! Click Here

Order Configurator

$0.00
Add to Project Folder Add to Project Folder
?

1 Lumens are nominal delivered lumens. See Photometry page for exact values.
2 Special Order. Minimum order quantity (MOQ), extended lead time may apply. Consult Factory.

347 Input with 0-10V available. Consult Factory for details and lead time.
Energy Efficient Chip-On-Board (COB) Singular LED Light source provides for smooth, uniform light output, eliminating the multiple shadow effect seen by multiple LED source products.
Binned with 3-Step MacAdam Ellipses as recommended by Ansi Standard. Available in 2700k, 3000k, 3500k, 4000k, 5000k.
Custom RAL Color: Please note that we appreciate custom finishes. Custom finishes are subject to a special paint setup fee for the quantity ordered. Extended lead times may apply. Consult Factory.

Dimming Diagrams
