CH9 : 9"/10" C • Series LED Downlight New Construction 1000lm-6200lm (9W-55W)

9"/10" C • Series LED Downlight New Construction 1000lm-6200lm (9W-55W) 9"/10" C • Series LED Downlight New Construction 1000lm-6200lm (9W-55W)
9"/10" C • Series LED Downlight New Construction 1000lm-6200lm (9W-55W)
9"/10" C • Series LED Downlight New Construction 1000lm-6200lm (9W-55W) 9"/10" C • Series LED Downlight New Construction 1000lm-6200lm (9W-55W) 9"/10" C • Series LED Downlight New Construction 1000lm-6200lm (9W-55W) 9"/10" C • Series LED Downlight New Construction 1000lm-6200lm (9W-55W)
Compatible Items Similar Items

Downloads

Add to Project Folder Add to Project Folder
?

Description

Architectural/Commercial-grade recessed lensed LED downlight housing suitable for medium to high ceilings in new construction installations.

Benefits

  • Twist and lock reflector for quick access to LED lamp array
  • Heavy-duty self-flanged reflector
  • Soft even lumen distribution
  • No visible screws or hardware
  • Multiple Wireless Control Options

Available Features
?

  • Chicago Plenum
  • Damp Location
  • Emergency
  • ETL Listed
  • IC Rated
  • US Assembled
  • Wet Location
  • Dedicated LED
  • Ambient Lighting
  • Downlight
  • Daylight Sensor
  • Occupancy Sensor
  • 120V
  • 277V
  • 347V
Inquire about this Product! Click Here

Order Configurator

$0.00
Add to Project Folder Add to Project Folder
?

1 Housing must match corresponding Reflector in column to right.
2 All drivers are 120V/277V unless otherwise noted.
3 Only available for EM Housings.
4 (-BWNG) option does NOT include Hanger Bars. Hanger Bars ordered separately.
5 (ICA) is only available on CH908, CH910 and CH915.
6 (-347-D10) not available for CH908.
7 Check Wiring Diagrams.
8 CH940/CR9L40 only available with UE-D10, UE-D10P1 and -347 dimming options.
9 Special Order.
10 (-SUN-RMT) sensor sent with mounting clips for existing ceiling applications.

Dimming Diagrams
