CRTR9L : 9"/10" C • Series LED Downlight Retrofit/Remodel - 1000lm-6200lm (9W-55W)

9"/10" C • Series LED Downlight Retrofit/Remodel - 1000lm-6200lm (9W-55W) 9"/10" C • Series LED Downlight Retrofit/Remodel - 1000lm-6200lm (9W-55W)
9"/10" C • Series LED Downlight Retrofit/Remodel - 1000lm-6200lm (9W-55W)
9"/10" C • Series LED Downlight Retrofit/Remodel - 1000lm-6200lm (9W-55W) 9"/10" C • Series LED Downlight Retrofit/Remodel - 1000lm-6200lm (9W-55W) 9"/10" C • Series LED Downlight Retrofit/Remodel - 1000lm-6200lm (9W-55W) 9"/10" C • Series LED Downlight Retrofit/Remodel - 1000lm-6200lm (9W-55W)
Compatible Items Similar Items

Downloads

Add to Project Folder Add to Project Folder
?

Description

Architectural/Commercial-grade recessed lensed LED retrofit/remodel downlight for low to high ceilings with existing open style frame.

Benefits

  • New Junction Box option for remodels without frames
  • Heavy Duty Tension Springs included
  • Twist and Lock reflector for quick access to LED lamp array
  • Heavy Duty Self-Flanged Reflector
  • No Visible Screws or Hardware
  • Multiple Wireless Control Options

Available Features
?

  • Chicago Plenum
  • Damp Location
  • Emergency
  • ETL Listed
  • IC Rated
  • US Assembled
  • Wet Location
  • Dedicated LED
  • Ambient Lighting
  • Downlight
  • Daylight Sensor
  • Occupancy Sensor
  • 120V
  • 277V
  • 347V
Inquire about this Product! Click Here

Order Configurator

$0.00
Add to Project Folder Add to Project Folder
?

1 All drivers are 120V/277V unless otherwise noted.
2 Check wiring diagram.
3 Special Order.
4 (-SUN-RMT) sensor sent with mounting clips for existing ceiling applications.
5 (ICA) is only available on CRTR9L08, CRTR9L10 and CRTR9L15.
6 (-347-D10) not available for CRTR9L08.
7 CRTR9L40 only available with UE-D10, UE-D10P1 and -347-D10 dimming options
8 UE-D10-EM is not compatible with -EM or -EMAC or -EMAC347 or -GTD

Dimming Diagrams
