CH4LS : 4" C • Series Lumen/ColorSelect New Construction 1800lm-2700lm (18W-28W)

4" C • Series Lumen/ColorSelect New Construction 1800lm-2700lm (18W-28W) 4" C • Series Lumen/ColorSelect New Construction 1800lm-2700lm (18W-28W)
4" C • Series Lumen/ColorSelect New Construction 1800lm-2700lm (18W-28W)
4" C • Series Lumen/ColorSelect New Construction 1800lm-2700lm (18W-28W) 4" C • Series Lumen/ColorSelect New Construction 1800lm-2700lm (18W-28W) 4" C • Series Lumen/ColorSelect New Construction 1800lm-2700lm (18W-28W) 4" C • Series Lumen/ColorSelect New Construction 1800lm-2700lm (18W-28W) 4" C • Series Lumen/ColorSelect New Construction 1800lm-2700lm (18W-28W)
Compatible Items Similar Items

Downloads

Add to Project Folder Add to Project Folder
?

Description

Architectural/Commercial-grade recessed LED downlight housing with Lumen/ColorSelect switch offers added flexibility for optimal light output and ambience in commercial and architectural spaces with medium to high ceilings.

Benefits

  • LumenSelect switch with 1800lm, 2300lm, or 2700lm setting
  • ColorSelect 3000K, 3500K, 4000K (84CRI) switch
  • Twist and lock reflector for quick access to LED lamp array
  • Heavy-duty self-flanged reflector
  • Soft even lumen distribution
  • No visible screws or hardware
  • Multiple Wireless Control Options

Available Features
?

  • Chicago Plenum
  • Damp Location
  • Emergency
  • ETL Listed
  • IC Rated
  • US Assembled
  • Wet Location
  • Dedicated LED
  • Ambient Lighting
  • Downlight
  • Daylight Sensor
  • Occupancy Sensor
  • 120V
  • 277V
Inquire about this Product! Click Here

Order Configurator

$0.00
Add to Project Folder Add to Project Folder
?

1 Housing must match corresponding Reflector in column to the right.
2 Only available for EM Housings.
3 (ICA) is only available on 1800lm (18W), and 2300lm (22W). (2700lm (28W) are Non-IC rated).
4 Check Wiring Diagrams.
5 Special Order.
6 (-SUN-RMT) sensor sent with mounting clips for existing ceiling applications.

Dimming Diagrams
