Description

Architectural/Commercial-grade recessed lensed LED downlight housing for medium to high ceilings in commercial and architectural spaces.

Benefits

  • Twist and lock reflector for quick access to LED lamp array
  • Heavy-duty self-flanged reflector
  • Standard with 0-10V Dimming
  • Soft even lumen distribution
  • No visible screws or hardware
  • Multiple Wireless Control Options

Available Features
?

Inquire about this Product! Click Here

Order Configurator

$0.00
Add to Project Folder Add to Project Folder
?

1 Housing must match corresponding Reflector in column to right.
2 All drivers are 120V/277V unless otherwise noted.
3 Only available for EM Housings.
4 (-BWNG) option does NOT include Hanger Bars. Hanger Bars ordered separately.
5 (ICA) is only available on CH408, CH410, and CH418. (CH428, CH429 and CH430 are Non-IC rated.)
6 (-347-D10) not available for CH408.
7 Check Wiring Diagrams.
8 (-T50) not available for CH429 and CH430.
9 Special Order.
10 (-SUN-RMT) sensor sent with mounting clips for existing ceiling applications.
11 Only available with CH408.

Dimming Diagrams

Energy Star Qualified Items

  • CR4L17_-T30
  • CR4L17_-T35
  • CR4L17_-T40
