LCMPD-REMA : LumenPad Recessed Emergency Backup (15W)
Description
The LumenPad Recessed Emergency Option is a slim, unobtrusive solution designed to maintain clean ceiling aesthetics while ensuring reliable emergency illumination. By eliminating the need for matching blank boxes, it provides a seamless integration into commercial, hospitality, and architectural spaces.
In the event of a power failure, the LED Emergency backup switches to the emergency mode and operates the existing fixture for 90 minutes. The 100 Vac output during emergency mode supplements the AC LED driver to power the fixture (≤15W).
The unit contains a battery, charger, and converter circuit in a single enclosure.
Features:
- Slim, low-profile design
- Junction box-free installation, no need for blank boxes.
- Long-life lithium battery, high-temperature & recyclable.
- Test switch & charge indicator for easy maintenance and monitoring.
- Supports switched & unswitched fixtures
- Simple 120VAC hookup
- Multiple knockouts for wiring flexibility – 7 × ½", 6 × ¾", 4 × 1".
- Meets NEC & Life Safety Code standards
"Available Q2"
Benefits
- Maintains clean and cohesive ceiling aesthetics.
- Provides reliable emergency illumination for safety and code compliance.
- Reduces installation costs by eliminating blank boxes.
- Ideal for commercial, hospitality, and architectural spaces.
- Built for durability with a long-lasting battery and sturdy construction.
- Simplifies testing and maintenance with built-in controls.
