CH9C : 9"/10" C • Series (COB) Chip on Board Beam Control LED, New Construction 1000lm-4000lm (10W-40W)

9"/10" C • Series (COB) Chip on Board Beam Control LED, New Construction 1000lm-4000lm (10W-40W) 9"/10" C • Series (COB) Chip on Board Beam Control LED, New Construction 1000lm-4000lm (10W-40W)

Description

Architectural/Commercial-grade recessed (COB) Chip on Board Beam Control LED allows for concentrated high center beam candlepower. Twist and lock TIR beam control optic is designed for easy field replacement of 20°, 30°, 40°, 60°, and 75° beam spread options.

Benefits

  • Assorted dimming options
  • COB LED design allows for concentrated high CBCP beam
  • Multiple Beam Spreads for flexible beam control
  • Quick connector power adapter and twist-and-lock reflector for quick access and easy maintenance
  • Multiple Wireless Control Options

Available Features
?

  • Chicago Plenum
  • Emergency
  • ETL Listed
  • IC Rated
  • US Assembled
  • Dedicated LED
  • Ambient Lighting
  • Downlight
  • Daylight Sensor
  • Occupancy Sensor
  • 120V
  • 277V
  • 347V

Order Configurator

1 All drivers are 120V/277V unless otherwise noted.
2 -347-D10 is not available for CH9C10.
3 Clear finish reflector not recommended for placing close to vertical surfaces. Uneven striations may be visible.
4 Check wiring diagrams.
5 ICA is only available for CH9C10, CH9C15, CH9C20, and CH9C30. (CH9C40 are Non-IC rated.)
6 Special Order.
7 (-SUN-RMT) sensor sent with mounting clips for existing ceiling applications.
