CRTR4LC : 4" C • Series (COB) Chip on Board Beam Control LED, Retrofit/Remodel 1000lm - 2500lm (10W-30W)

4" C • Series (COB) Chip on Board Beam Control LED, Retrofit/Remodel 1000lm - 2500lm (10W-30W) 4" C • Series (COB) Chip on Board Beam Control LED, Retrofit/Remodel 1000lm - 2500lm (10W-30W)
4" C • Series (COB) Chip on Board Beam Control LED, Retrofit/Remodel 1000lm - 2500lm (10W-30W)
4" C • Series (COB) Chip on Board Beam Control LED, Retrofit/Remodel 1000lm - 2500lm (10W-30W) 4" C • Series (COB) Chip on Board Beam Control LED, Retrofit/Remodel 1000lm - 2500lm (10W-30W) 4" C • Series (COB) Chip on Board Beam Control LED, Retrofit/Remodel 1000lm - 2500lm (10W-30W) 4" C • Series (COB) Chip on Board Beam Control LED, Retrofit/Remodel 1000lm - 2500lm (10W-30W)
Compatible Items Similar Items

Downloads

Add to Project Folder Add to Project Folder
?

Description

Architectural/Commercial-grade recessed (COB) Chip on Board Beam Control LED allows for concentrated high center beam candlepower. Twist and lock TIR beam control optic is designed for easy field replacement of 25°, 30°, 50°, 60°, and 70° beam spread options.

Benefits

  • Heavy-duty seamless die-cast reflector
  • Assortment of dimming options
  • COB LED design for concentrated high CBCP beam
  • Multiple beam spreads for flexible beam control
  • Twist and lock reflector for quick access to LED lamp array
  • Multiple Wireless Control Options

Available Features
?

  • Chicago Plenum
  • Emergency
  • ETL Listed
  • IC Rated
  • US Assembled
  • Dedicated LED
  • Ambient Lighting
  • Downlight
  • Daylight Sensor
  • Occupancy Sensor
  • 120V
  • 277V
  • 347V
Inquire about this Product! Click Here

Order Configurator

$0.00
Add to Project Folder Add to Project Folder
?

1 All drivers are 120V/277V unless otherwise noted.
2 -347-D10 is not available for CRTR4LC10.
3 Clear finish reflector not recommended for placing close to vertical surfaces. Uneven striations may be visible.
4 (ICA) is only available for CRTR4LC10, CRTR4LC15, and CRTR4LC19. (CRTR4LC25 are Non-IC rated.)
5 UE-D10-EM is not compatible with -EM or -EMAC or -EMAC347 or -GTD.
6 Check Wiring Diagrams.
7 Special Order.
8 (-SUN-RMT) sensor sent with mounting clips for existing ceiling applications.

Dimming Diagrams
